Type of wrapping: Vertical Maximum height: Up to 2.400 mm (consult about other heights)
Maximum dimensions pallet and load: 1.200 x 1.100 mm (consult about other dimensions)
Maximum weight: 2.000 Kg
Technical features
- Hinged mast
- Powered film carriage with variable speed, placed sidewise
- Adjustable mechanical film brake with foot trapping detector
- Automatic load height detection by photocell
- Platform dimensions: Ø1.500 mm
- Soft start/stop by frequency inverter with return to start position
- 4 wrapping programs: Single, Cross wrap, Cross-plus, full
- Wrapping cycles counter
- Independently adjustable top & bottom reinforcement wraps
- PLC controlled, with LCD display control panel
- Reinforcement wraps at any point in the cycle
- Ergonomic control panel
- Variable output, depending on load features and operator ability
- Electric power: 220 V 50 Hz
- Installed power: 0,5 kw
Standard pallet features (others on demand)
- Type of wrapping: Vertical
- Maximum height: Up to 2.400 mm (consult about other heights)
- Maximum dimensions pallet and load: 1.200 x 800 mm
- Maximum weight: 1.000 kg
Options and accessories
- Adjustable mechanical film brake with foot trapping safety (standard)
- Electromagnetic brake with foot trapping safety
- “M” film pre-stretch with foot trapping safety
- Powered top platen
